PRO-Lite Aluminum Shield
OSHA compliant, the PRO-Lite aluminum shield (trench shoring box) is about as simple and user-friendly as it can get. Weighing in at only 60 Lbs. per panel, the PRO-Lite provides cave-in protection for trenches up to 12’ deep in C60 Soils. Like all Prospan products, compliance has never been easier. PRO-Lite panels are stackable to a maximum height of 12 feet.
The PRO-Lite is so lightweight and easily assembled that a separate shoring trailer may not be needed at all. At only a few inches thick and a mere 36″ tall, the PRO-Lite can be carried directly on most vehicles. Gone are the excuses for not having a protective system with you at all times.
Spreader Bars come in various sizes and our Adjustable Leg Kits enable the PRO-Lite to be positioned a maximum of 24″ above the floor of the trench.
36″ SIDE PANELS
Table is horizontally scrollable
| Model | Dimensions – HxLxW | psf Rating | Weight Per Pair | Bury Depth | PRICE |
|---|---|---|---|---|---|
| PL36-60 | 36″ x 60″ x 2″ | 792 | 120 lbs | 12 ft | Call Prospan |
* Price includes 2-panels. Requires (2) Spreader Bars
36″ END PANELS
Table is horizontally scrollable
| Model | Dimensions – HxLxW | psf Rating | Weight Per Panel | Bury Depth | PRICE |
|---|---|---|---|---|---|
| 36-60 | 36″ x 60″ x 2″ | 792 | 60 lbs | 12 ft | Call Prospan |
* Price includes 1-panel & (4) Pins
SPREADER BARS
Table is horizontally scrollable
| Model | Length | Shield Width | Weight Per Spreader | Bury Depth | PRICE |
|---|---|---|---|---|---|
| SB-19 | 19″ | 2′ | 4 lbs | 12 ft | Call Prospan |
| SB-31 | 31″ | 3′ | 7 lbs | 12 ft | Call Prospan |
| SB-43 | 43″ | 4′ | 10 lbs | 12 ft | Call Prospan |
| SB-55 | 55″ | 5′ | 12 lbs | 12 ft | Call Prospan |
| SB-67 | 67″ | 6′ | 15 lbs | 12 ft | Call Prospan |
| SB-79 | 79″ | 7′ | 18 lbs | 12 ft | Call Prospan |
ACCESSORIES
| Stacking Tubes (set of 4) | Attaches two shields |
| Adjustable Leg Kit | Adjustable in 12″ increments upto 24″ |
| Lifting Sling | Bridle Sling |
CORRECTION: Weight per Pair = 120 LBS
click image to enlarge
Product Applications
The "Prospan way" is to use the right tool for the right job. If the job involves trench applications, structural applications, or vehicular applications, we have the right tool for you.
Trench Applications
Our patented Prospan products are cutting-edge in terms of safety for trench shoring applications. In most cases, plywood is unnecessary when using the Prospan, and your workers’ safety is better ensured with our anti-projectile protection.
Prospan products are only allowed to be under air pressure when they are shoring a trench. View Trench Kits
Structural Applications
When natural or man-made disasters strike, the stability of buildings and other structures is always a top concern for first responders trying to ensure the safety of others. We help ensure the safety of first responders and others working in potentially hazardous environments.
Prospan shoring products are designed to telescope toward their target. In some instances, the Prospan can support loads in excess of 40,000 pounds. View Structural Kits
Vehicle Applications
Automobile accidents provide thousands of opportunities for Prospan shoring products to be used annually. When a vehicle needs to be stabilized after a crash, our telescoping screw-jack system has been proven to be among the strongest in the world.
Prospan products hold up under the harshest conditions and are simple to maintain because of their minimalist design. View Vehicle Kits
Tabulated Data governing the use of these products has been approved and stamped by a Registered Professional Engineer.
These data are mandatory and shall be adhered to without exception. DOWNLOAD ENGINEERING DATA
